Level Transmitters

Leading Manufacturers, Exporters and Wholesaler of Submersible Level Transmitter, Ultrasonic Level Transmitters, Magnetic Float Level Transmitter, Capacitance Level Transmitter, Smart Displacement Level Transmitter, Magnetic Bi Colour Level Transmitter, Float Operated Level Transmitter and Ultrasonic remote Level Transmitter from Delhi.

15,000.00 - 1 Lac / Piece

1 piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA
Material Metal
Condition New
Application For Liquid Measuring
Type Level Transmitters
Country of Origin India
Sensor Material SS 316L
Measuring Range 5/10 mtrs – 100mtrs
Cable Polyethylene
Process Temeperature Amp.
Compensation Full Scale
Protection IP68
Supply 24V DC Loop
Output 4-20 mA, 2 wire
Technical Specification View
Product Code LFT1

Click to view more

Preferred Buyer From

Location Anywhere in India

Industrial Submersible Level Transmitter probe are compact device for continuous level measurement of non-aggressive liquids (without solid impurities) in non-pressurised tanks, vessels, reservoirs, sumps & tanks.


Probe consists highly stable piezo resistive sensor and precise evaluation electronics in stainless steel housing. Probe is sealed, thus protect its pressure from mechanical damage. A cable is integral of probe, consists of 2 wires & a capillary tube comes in various range as per requirement. Other end of capillary tube is kept open to atmosphere for air to flow freely(for atm. pressure compensation).

Transmitter is simply hanged inside tank through its cable. The sensor transducer is enclosed in a liquid tight SS316 hosing and assembled to a liquid proof cable. Due to liquid static pressure inside tank, transducer signal is converted into 4-20 mA( 2 wire) output is correspond to liquid level accurately. The change in level is detected by comparing the pressure difference between pressure of water column over the probe & atmospheric through capillary tube. This generates a output signal which is converted into 4r20mA (2-wire) signal.

Features :

  • Long measuring range, customised length.
  • Extension Cable, Flanged model
  • IP 68 sealed probe of SS
  • Easy to install, operate, no moving part, high accurate.
  • Special polyurethane cable ensuring more flexible & endurable.
  • Reliable, Economical.
Read More...


Request to Call


28,000.00 - 40,000.00 / 1 Unit

1 Piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA
Material PP,PP
Color Blue, Grey
Condition New
Application For Liquid Measuring, Big Storage Tanks
Type Level Transmitters
Frequency 0-25Ghz
Accuracy 0.25%
Country of Origin India
Signal output 0-20mA
Ambient Temperature -10 Deg. C - 60 Deg. C
Output Signal 4-20 mA
Power Consumption Less than 0.8 W
Full Scale 5,8,10 m
Max Measure Error 0.3% On Full Scale
Technical Specification View
Product Code LFT2

Click to view more

Preferred Buyer From

Location Anywhere in India

Ultrasonic Level Transmitter of two wires serial is a sealed transducer best suited for applications where harsh or hazardous environments are a problem. Been made of energy conservation components, It can work between DC 9"32v power supply. Only two wires are enough to supply power and acquire the measured value. LCD display is convenient for onsite setting.

Application:

  • Wastewater treatment
  • Proximity Detection
  • Sedimentation pool
  • Coal washing process
  • Obstacle detection, collision avoidance
  • General purpose distance detection


Features:

  • High precise
  • Strong anti-interference
  • Automatic temperature compensation
Read More...


Yes! I am interested


15,000.00 - 1 Lac / Piece

1 piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA
Material Stainless Steel
Color Blue
Condition New
Application For Liquid Measuring
Type Level Transmitters
Country of Origin India
MOC SS/ PP
Operating Temperature 100 Deg. C (45 Deg. C for PP models)
Operating Pressure 10 kg/cm2
Mounting Top
Resolution 15mm
Housing Aluminium, Weather Proof, Exp. Proof
Connection Flange/Threaded
Pipe Length Up to 3000mm
Supply 24V DC loop
Output 4-20 mA, 2 wire
Technical Specification View
Product Code LFT3

Click to view more

Preferred Buyer From

Location Anywhere in India

The magnetic float level transmitter devices using the principles of buoyancy and magnetism to generate a changing electrical output in response to the rise and fall of the float on the sensing guide rod.

The magnetic float level transmitter provides a 3-wire resistance output or can be equipped with an appropriate level transmitter to provide a 4-20mA analog signal indicating liquid level.

The sensing guide rod includes a series of reed switches along the entire measuring length. Placement of reed switches provides either of two possible measuring resolutions.

As the float is raised or lowered by the liquid level, the sensing rod will induce a resistance output, which is directly proportional to the liquid level.

The Magnet Float Level Transmitter is a sturdy, reliable and durable device that is applicable across most industries.

Features :

  • Reliable, Maintenance free.
  • SS or PP construction
  • Easy to install & operate
  • Explosion Proof certificate available
Read More...


Request to Call


12,000.00 - 18,000.00 / 1 Piece

1 Piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA,LFIA
Material Stainless Steel
Color Blue, Grey, Silver
Condition New
Application For Liquid Measuring
Type Level Transmitters, Capacitance
Country of Origin India
Range 3MTR
Signal output 0-20mA
Output 4-20 mA, 2 wire loop
Probe Material SS Rod/Rope insulated party or fully with PTFE
Temperature -20 to 100 Deg C or Special (upto 200)
Electronics -15 to 65 Deg C
Housing Aluminium, Weather Proof
Connection 1/2
Voltage Supply 12-30VDC
Technical Specification View
Product Code LFT4

Click to view more

Preferred Buyer From

Location Anywhere in India

Capacitance Level Transmitter is a compact, low cost, level transmitter with 4-20 mA analogue out-put designed to measure the level of various liquids, and solid in tanks or storage vessels. Mea-suring range is 0.25 to 3 m for rod probe version. The probe forms an electrical capacitor with the surrounding metal contained wall, or with auxiliary reference probe. With the vessel empty, an initial ca-pacitances exists between the electrode And the metal well or the aux-iliary reference probe.

When the probe become covered with material to be measured the capaci-tances will increase and the change will be measured and covered into an analogue (4-20 mil) output signal proportional to the change. Rod or flexible cable can be used for various conductive or non conductive Liquids.

Conductive Material:

  • Water based solutions. Acids based etc only insulated probe are suggested


Non Conductivity Material:

  • Mostly petrochemical and solvents insulated or non insulated probes can be used
Read More...


Request to Call


1.50 Lac - 1.80 Lac / Piece

1 Piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA
Material Monel, Hastelloy, SS, etc,Monel, Hastelloy, SS, etc
Color Blue, Grey, Silver
Condition New
Application For Liquid Measuring, Industrial
Type Level Transmitters, Digital
Frequency 0-25Ghz
Country of Origin India
Signal output 0-20mA
Isolated Power Supply 35V dc for explosion proof b) 30V dc for intrinsically safe
Operatine Amb, Temp. 65 Deg C
Zero Adjustability 15% of Sensing Element Range
Damping 32 Seconds
Specific Gravity 0.3 to 1.2
Display LCD
Product Code LFT5
Payment Terms Other

Click to view more

Preferred Buyer From

Location Anywhere in India

Smart Displacement Type Level Transmitter is designed to sense Liquid level, Interface and Specific gravity. The output of the Instrument is proportional and is designed to measure and transmit electrical signal proportional to changes in Liquid level or Specific Gravity.

The LFIA series measures changes in Liquid Level, Specific Gravity or Interface Level and transmits a current output signal proportional to the change in the process parameter. The change in the process parameter causes a change in the displacer position, which is transferred to the Torque Tube producing a rotary motion. This rotary motion is transferred through bellow to lever assembly that is supported by flexure strips. Magnets attached to the lever assembly move past a Hall effect position sensor that converts the magnetic field signal to an electrical 4- 20mAsignal.

Read More...


Request to Call


20,000.00 - 30,000.00 / Piece

1 piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA
Material Stainless Steel, SS / PP,SS/PP
Color Grey, Silver
Condition New
Application Chemicals / Hot Water,Diesel
Type Level Transmitters
Country of Origin India
Signal output 0-20mA
Ambient Temperature 50 DC
Measuring Range Upto 3 Mtr.
Process Connection Flanged
Mounted Side / Top
Indicator Red & White Bi- Colour Magnetic Roller Flapper Strip
Operating Pressure 15 Bar / 60 Bar
Product Code LFMBC

Click to view more

Preferred Buyer From

Location Anywhere in India

Magnetic Level Indicator float moves with level in external chamber (cage) which is coupled with the tank. Indication display mechanism does not come in direct contact with the liquid media. Special designed cylindrical magnetic float as per density of liquid. Magnetically coupled follower capsule or roller or ball indicates the liquid level externally. Indicator system is consists of bi-colour rollers equipped with magnets mounted on rail inside the housing. As the level starts rising or falling magnetic float also travels with liquid level in non-magnetic chamber. The magnetic interaction between magnets in float and bi-colour rollers causes each roller to rotate 180o. These red / white rollers are visible from long distance, giving a good visual indication visibility. Models are available with side & top mounting designs.

Application

Liquid, Acids, machines, food, Diesel, Oil, Condensate, Chemicals, Beverages, etc.

Features :

  • Visible level changes are shown by the flag display.
  • Compact & easy to install.
  • Rugged, Life long, good visibility.
  • Optional - Level switches for alarm or controlling.
  • Optional - Level transmitters with 4 - 20 mA signal output.
  • SS304, SS 316 & PP version for acid applications
Read More...


Request to Call


13,000.00 - 18,000.00 / Piece

1 Piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA
Material Aluminium,Alluminium
Color Blue, Grey
Condition New
Application For Liquid Measuring, Industrial
Type Level Transmitters, Float Operated
Frequency 25-50Ghz, 50 Hz
Country of Origin India
Ambient Temperature 100 Deg C
Output Signal 4-20mA
Product Code LFT3
Payment Terms Other

Click to view more

Preferred Buyer From

Location Anywhere in India

Level transmitters are reliable and accurate sensors for continuous level indication and control of any liquid, liquid / liquid interface detection, chemically Compatible with the (sensor) material which are intrinsically safe, unaffected by electrical conductivity, temperature, pressure or viscosity

  • The float is designed for variety of liquids and its unique self-cleaning construction is well suited for even sticky or dirty environments with no float hang-ups
  • Multiple alarm relays adjustable option, HART, RS-232, RS-485 options are available
  • The transmitters are Pre-calibrated in the factory. No need of field calibration
  • The accuracy of the transmitter an be as high as 0.1mm

 Application : Diesel, Generator facilities, Petrochemical, Condensate, acids, chemical, beverages, milk, juices, oil, cooling tower etc



Features :



  • Reliable, Maintenance free
  • SS or PP construction
  • Easy to install and operate
  • Explosion Proof certificate available
Read More...


Request to Call


50,000.00 - 80,000.00 / 1 Piece

1 Piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier
Brand Name LFIA
Material Stainless Steel
Color Grey
Condition New
Type Level Transmitters
Frequency 0-25Ghz, 20 KHz
Country of Origin India
Range 5/8/10/15/30 Mtrs.
Signal output 0-20mA
Output 4-20 mA,2 wire
Power Supply 24V DC
Dead Zone 300,500 mm
Temperature 0-60 Deg C
Response Time 500 ms
Display LCD Display
Programming By push Button
Housing ABS
Application For Liquid Measuring
Product Code LFT2
Port BY COURIER / TRANSPORT
Delivery Time 1 week

Click to view more

Preferred Buyer From

Location Anywhere in India

Ultrasonic Level Remote Transmitter of two wires serial is a sealed transducer best suited for applications where harsh or hazardous environments are a problem. Been made of energy conservation components, It can work be-tween DC 9-32v power supply. Only two wires are enough to supply power and acquire the measured value. LCD display is convenient for onsite setting.



Application:

  • Diesel storage tanks, Water, Storage tanks, waste water treatment, pits, ponds, sewage acids, solvent, juice, beverages etc



Features:

  • Easy Calibration Programming
  • Strong waves
  • LCD display
Read More...
