Displacer Type Level Switch

Displacer level switch is used where High temperature and High Pressure liquid level control is required. It gives potentional free 5A@250VAC 1C/0 or 2C/0 contacts for direct interface to Solinoide Valves, Relays Contactors, and Panel Lamps etc.Application : Water, Foaming or surging liquids, oils, large storage tanks, juices, etc.

Features :

• Displacers adjustable at any point along the suspension cable
• Flanged or threaded mounting available
• Easy installation, economical, long range.
• Field adjustable set point and switch differential.
• Single or multiple level sensing.

• Displacer Type Level Switch offer the indus-trial user a wide choice of alarm and control con-figurations. Each unit utilizes a simple buoyancy principle and are well suited for simple or com-plex applications, such as foaming or surging liq-uids. Displacer type level measurement units are wide differential units calibrated to actuate as a liquid level reaches a given displacer and to de-actuate when the level reaches a second displacer. Single stage, wide differential displacer switch-es are factory calibrated yet field adjustable to operate over a wide level differential band.



  Application:

  • Water, Foaming or surging liquids, oils large storage tanks, juices etc


  Operating Principle:

  • Suitable for the highly dusty environment
  • No frequent calibration required easy to use and durable design
  • Suitable for liquid, powder and solid application
  • SPDT relay output

  Features:

  • Displacers adjustable at any point along the suspension cable
  • Flanged or threaded mounting available
  • Easy installation, economical, long range
  • Field adjustable set point and switch differential
  • Single or multiple level sensing
